Feature:
1. Wireless 2.4G Transmission: This code scanning gun adopts wireless 2.4G transmission, which is very stable and can reach up to 80m in the open space.
2. High Capacity Lithium Battery: This barcode scanner adopts 2000mAh high capacity lithium battery, which can be used continuously for more than 15 hours after 4 hours of charging.
3. Wide Application: This barcode scanner is suitable for various scenarios, shopping malls and supermarkets, pharmacies and hospitals, restaurants and dessert stores, clothing stores, etc.
4. High Performance Decoder Chip: This code scanning gun adopts high performance decoder chip, which can decode faster and improve the efficiency greatly.
5. High Strength Shell: This barcode scanner is made of excellent ABS and PC material for the shell, which is sturdy and wear resistant, and has more stable anti vibration and anti drop performance.
Specification:
Item Type: Bar Code Reader
Material: ABS, PC
Scanning Mode: CMOS Image Based Scanning
Resolution: 752 x 480 Pixels
Light Source: 265LX (130NM)
Light Source Type: LED (650NM))
Scanning Speed: 200 Times S
Accuracy: more than 5mil
Printing Contrast: more than 30percent
Maximum Power: 1.33W
Voltage: (3.3V 5V) + 5percent
Maximum Current: 330mA
Sleep Current: 50uA
Standby Time: 30 Seconds Into Standby
LED Indication:
Connection LED: Green
Scanning Indicator: Red
Data Interface: Support USB, RS232 Interface, Drive Free Operation
System: for WINDOWS, for LINUX
Reading Distance: Approx. 20cm 7.9in
Communication Distance: Wireless 80M In The Open Distance
Battery Alarm: Buzzer sounds five times in a row.
Scanning Width: 30MM at Scanner Window, 220MM at 200MM
Scanning Angle: Rotate 30 degrees , Tilt + 65 degrees , Deflect + 55
Alerting Method: Buzzer, LED Indicator Light
Usage: 63000 Times
Housing Material: ABS + PC
Operating Temperature: 0 celsius 50 celsius (32 degrees F 122 Fahrenheit )
Storage Temperature: 40 celsius 60 celsius ( 40 Fahrenheit 140 Fahrenheit )
Relative Humidity: 5percent 95percent ( Non Condensing )
Peripheral Illumination: 0 100000lx
Electrostatic Protection: + 8KV ( Contact Discharge ), + 15KV ( Air Discharge )
Drop Height: Approx. 1.5m 4.9ft
IP Rating: IP54
Decoding Capability:
2D: PDF417, MICROPDF417, QR CODE, DATAMATRIX
1D: UPC A, UPC E1, UPC EO, EAN 13, EAN 8, ISB(BOOKLAND EAN), ISSN, CODE 39, CODE 39 FULL ASCII, CODE 32, TRIOPTIC CODE 39, INTERLEAVED 2 OF 5, INDUSTRIAL 2 OF 5, CODABAR (NW7), CODE 128, ISBT 128, CODE 93, CODE 11 (USD 8), MSI, for PLESSEY, UK, for PLESSEY, UCC, EAN 128, for CHINA POST, for CHINA FINANCE, GS1 DATABAR (FORMERLY RSS) VARIANTS
Battery: Rechargeable Lithium Battery 2000mah x 1 ( Shipped With Built In Battery ).
Package List:
1 x Bar Code Reader1 x Connection Cable1 x Wireless Receiver1 x Manual
