ESP32-C3 Development Board ESP32 C3 SuperMini WiFi Bluetooth-Compatible Board Development Board CORE Board Compatible with Arduino
Feature:
1. Powerful CPU Integration:Experience high performance with the ESP32-C3, a 32-bit RISC-V single-core processor that boasts up to 160 MHz. This development board is equipped with WiFi 802.11b/g/n protocols at 2.4GHz supporting Station mode, SoftAP mode, SoftAP+Station mode, and mixed mode, along with Bluetooth-Compatible 5.0, ensuring a connection for all your IoT projects.
2. Ultra-Low Power Consumption:Designed for efficiency, the supermini development board features an ultra-low power consumption with deep sleep power usage at approximately 43uA. Its compact size (22.52x18mm) makes it for wearable devices and small projects, without compromising on performance.
3. Abundant On-Board Resources :The development board core board comes loaded with 400KB SRAM and 384KB ROM, including an in-built 4M flash, providing ample storage for your applications. The ESP32C3FN4 chip model ensures a powerful yet efficient performance for a wide range of applications.
4. Advanced Security Features:With the IoT board, security is a priority. It supports AES-128/256, hash encryption hardware accelerators, RSA, HMAC, digital signatures, and secure boot, offering reliable protection for your IoT solutions and safeguarding your data from potential threats.
5. Versatile Connectivity and Components: The dev board is designed with flexibility in mind, featuring 1xI2C, 1xSPI, 2xUART, 11xGPIO (PWM), and 4xADC interfaces for extensive connectivity options. Its single-sided component layout with surface-mount design and an onboard blue LED on GPIO8 pin makes it highly adaptable for various development needs.
Specification:
Origin: Mainland China
Type: Module
Condition: New
Product size: 25.00x18.00x12.00mm
Product size: 0.98x0.71x0.47inch
Product description:
ESP32 C3 SuperMini board is an IoT mini development board based on Espressif ESP32-C3 WiFi/Bluetooth-Compatible dual-mode chip. ESP32-C3 is a 32-bit RISC-V CPU that contains FPU (floating point unit) for 32-bit single-precision operations and has powerful computing power. It has excellent RF performance and supports IEEE 802.11b/g/n WiFi and Bluetooth-Compatible 5(LE) protocols. The board is equipped with an external antenna to enhance the signal strength of wireless applications. It also has a small and exquisite appearance and a single-sided surface mount design. Equipped with rich interfaces, it has 11 digital I/OS that can be used as PWM pins and 4 analog I/OS that can be used as ADC pins. It supports four serial interfaces: UART, I2C and SPI. The board also has a small reset button and a bootloader mode button. Combining the above features, ESP32C3SuperMini is positioned as a high-performance, low-power, cost-effective IoT mini development board suitable for low-power IoT applications and wireless wearable applications.
1. Powerful CPU: ESP32-C3, 32-bit RISC-V single-core processor, running at up to 160 MHz
2. WiFi: 802.11b/g/n protocol, 2.4GhHz, supports Station mode, SoftAP mode, SoftAP + Station mode, mixed mode
3.Bluetooth-Compatible:Bluetooth-Compatible 5.0
4. Ultra-low power consumption: deep sleep power consumption is about 43uA
5. Rich board resources: 400KB SRAM, 384KB ROM built-in 4Mflash.
6. Chip model: ESP32C3FN4
7. Ultra-small size: as small as a thumb (22.52x18mm) classic shape, suitable for wearable devices and small projects
8. Reliable security features: support AES-128/256, hash encryption hardware accelerator. RSA, HMAC, digital signature, secure boot
9. Rich interfaces: 1xl2C, 1xSPI, 2xUART, 11xGPIO (PWM), 4xADC
10. Single-sided components, surface mount design
11. Onboard LED blue light: GPIO8 pin
Note:
Due to the different monitor and light effect, the actual color of the item might be slightly different from the color showed on the pictures. Thank you!
Please allow 1-2cm measuring deviation due to manual measurement.
1 x Development Board (Soldered Pins)
or
1 x Development Board (Unsoldered Pins)
