Ayzeze: Safely charging your e-bike or e-scooter
• Don’t leave your battery unattended while charging, when you're out or while you're asleep
• Don’t cover chargers or battery packs when charging
• Don’t overload sockets or use unsuitable extension chords
• Don’t charge or store batteries in direct sunlight or in areas with temperatures above 45⁰C
• Don’t charge batteries next to combustible materials or hazardous substances
• Always unplug your charger once you have finished charging
• Always make sure to only use the proper proprietary charger
• Always ask a professional when converting your e-bike or e-scooter
• Always check your battery (and charger) for visible damage
-----
🏍️ Motocross Aesthetics Born from Competition
The KuKirin X1 isn't just designed for performance—it's designed to turn heads. With its iconic motocross proportions, asymmetric 14/12-inch wheel setup, distinctive Racing Orange finishes, aggressive geometry, and ergonomic "narrow waist" saddle, it creates a true man-machine connection.
⚡ 2000W Peak Power Motor
The 1000W motor (2000W peak) delivers the power you need—from city streets to the toughest trails. The KuKirin X1 is built for explosive torque; its 2000W mid-mounted motor concentrates weight at the core for highly responsive maneuverability. Thanks to its chain drive system, it easily conquers steep slopes, deep mud, and technical jumps, reaching a top speed of 50 km/h.
🔋 20.8Ah Battery
Eliminate range anxiety with a high-capacity modular battery. With 20.8Ah of reliable energy, this battery powers every ride, no matter where the road takes you. The KuKirin X1 offers a sporty range of 40 km and a quick-release system that lets you swap the battery in seconds or charge it independently to continue the adventure.
🔌 Dual Charging System & Removable Battery
Charge quickly via the external frame interface or remove the battery for indoor charging. It offers the perfect combination of convenience and portability for riders on the go.
🛡️ Triple Safety Design
Instant magnetic switch: immediate power cut in case of a fall.
Safe start: ignition key plus dedicated power button for secure launch.
Total control: reliable, controlled start every time you set foot on the trail.
📊 High-Brightness Color Display
Stay informed with the KuKirin X1's high-brightness color display. Even under direct sunlight, you can clearly see speed, assist level, and battery status, keeping you in full control of your machine.
🏔️ Elite Suspension & All-Weather Durability
With full IP65 waterproof rating and professional hydraulic damping, conquer challenging environments. The KuKirin X1 filters out 90% of surface vibrations, provides firm support on hard landings, and its sealed electronic system allows worry-free riding in rain and mud.
🛡️ Uncompromising "Safety First" Engineering
Total peace of mind when pushing the ride to the limit. The KuKirin X1 is equipped with a magnetic switch that instantly cuts power in case of a fall, a dedicated P mode to prevent unintended acceleration, and an intelligent E-ABS vector braking system that prevents wheel lock-up.
🗒️ Specifications
Brand: KuKirin
Model: X1
Frame material: 6061 aluminum alloy
Motor type: Mid-mounted motor (with reduction gearbox)
Motor voltage: 48V
Acceleration mode: Sine wave
Rated power: 1000W
Instantaneous peak power: 2000W
Rated motor speed: 2400 rpm
Maximum motor torque: 24 N·m
Battery type: 18650 ternary lithium battery
Battery voltage: 48V
Battery capacity: 20.8Ah
Standard power consumption: 998.4 kW·h
Battery protection system: Protection board (BMS)
Charger input voltage/current: 100-240V AC ~ 50/60 Hz, 2.5A
Charger output voltage/current: 54.6V ± 0.2, 2.5A
Charging time: 8.5-9 hours
Speed levels: 1st (25 km/h), 2nd (35 km/h), 3rd (50 km/h)
Maximum speed with 65 kg load: 50 km/h
Range at average speed (60 kg load, full battery to depletion): ≤40 km
(Specific range is affected by rider weight, temperature, riding speed, road conditions, and other factors.)
Tire type: Inflatable off-road tires
Optimal tire pressure: 225 kPa (32 psi)
Tire size: 14 inches front, 12 inches rear
Brake system: Front/rear hydraulic brakes + electronic brake
Front and rear suspension: Hydraulic damping
Display type: LED color display
Steering angle: 44°
Climbing angle: ≤15°
Headlight: LED
Brake disc specifications: 3 × 190 mm
Braking distance: 4-6 m
Seat height: 695 mm
Ground clearance: 207 mm
Wheelbase: 1095 mm
Protection rating: IP65
Maximum load: 120 kg
Net weight: 52 kg ± 0.5 kg
Gross weight: 60 kg ± 0.5 kg
Product dimensions: 1575 × 644 × 990 mm
Package dimensions: 1345 × 310 × 620 mm
📦 Package Contents
1 × KuKirin X1 off-road motorcycle
1 × Charger
1 × Tools
1 × User manual
