Simultaneous HDMI + USB 3.0 Output: Supports HDMI 4K USB camera, Ultra HD USB 3.0 HDMI camera, maximum resolution 3840x2160, and high-speed USB 3.0 interface up to 5GBPS 10X. Supports three operating modes: USB mode / HDMI mode / USB + HDMI simultaneous output mode.
4K 60fps 5-50mm 10X Manual Optical Zoom Lens: 4K Ultra HD USB3.0 HDMI Camera, 4K USB & HDMI camera with 1/2.8-inch CMOS IMX415 color CMOS image sensor, 4K high-pixel technology for sharp images and accurate color reproduction. Ultra HD shooting allows you to see even the smallest details clearly, and you can adjust parameters such as zoom, brightness, and sharpness by rotating the lens.
60FPS USB3.0 High-Speed 4K Camera: High-speed 60fps 4K USB 3.0 & HDMI camera, USB 3.0 output resolution and frame rate: Maximum resolution 3840x2160, capable of driving 3840x2160 MJPEG 60fps/H.264 60fps. HDMI output supports 4K 60fps, achieving extremely smooth and fluid streaming.
UVC compliant plug and play: Simply connect the camera to your PC computer, laptop, Android device, or Raspberry Pi with a USB cable, or connect it directly to a monitor with an HDMI cable, without installing any additional drivers.
Multiple compatibility and various usage opportunities: A great zoom-in and zoom-out camera suitable for research, technical or hobby projects, Raspberry Pi projects for recording bird feeding, bird feeders, and maintaining recordings in a loop, especially outdoors where you can get a satisfactory long-range focus.
Main specifications:
Model: IF-USB4KCAM30H-CFV(5-50Y)
Sensor: 1/2.8 inch CMOS IMX415
Maximum resolution: 3840(H)*2160(V)
Sensitivity: 0.65V/luxsec @ 550nm
Pixel size: 1.45μm x 1.45μm
Video compression: MJPEG / YUY2 (YUYV) / H.264
Resolution and frame rate:
3840x2160 MJPEG 60fps / H.264 60fps / YUY2 15fps
2560x1440 MJPEG 60fps/ H.264 60fps/
1920x1080 MJPEG 60fps / H.264 60fps / YUY2 60fps
1280x720 MJPEG 60fps / H.264 60fps / YUY2 60fps
640x480 MJPEG 60fps/H.264 60fps/YUY2 60fps
Image processing time: Approximately 10 seconds after opening the preview software. Center definition: 1000LW/PH (center)
S/N ratio: 30dB
Minimum illuminance: 0.2Lux
Shutter type: Electronic rolling shutter / Frame exposure
Connection port type: USB 3.0 interface & HDMI v1.4 interface
AEC/AWB/AGC: Support
Adjustable parameters: Brightness, contrast, saturation, hue, sharpness, gamma, white balance, backlight compensation, exposure. Lens parameters: CS 5-50mm lens (CS 2.8-12mm is optional).
Power and Interface: USB Type-C power, simultaneous connection of Type-C and HDMI display.
Operating voltage: DC 5V
Working current: 700-780mA
Storage temperature: -20°C to 80°C
Operating temperature: -10°C to 70°C
USB cable: 1.2m cable with Type-C port
HDMI cable: 1.5m cable with HDMI port
Operating system request:
Linux distributions with UVC support, such as Windows 7/8/9/10/11, Mac OS X 10.4.8 or later, and Android 5.x or later.
