Sensor Infrared Detection Photoelectric Sensing Switch Distance Security Alarm Parts DC5‑24V

Feature: 1. With adjustable delay closing time and sensing distance, wide sensing range and high accuracy. 2. Can sense the infrared rays radiated by the target, and use the physical properties of infrared rays to measure. 3. The sensor integrates infrared emission, reception and intelligent control, with strong practicability. 4. Using PC‑V0 fireproof material, flame retardant and impact resistance, has high safety factor. 5. Easy to install and does not take up space, often used in security alarms, sensor lights, smart trash cans, vending machines, faucets, etc.

Specification: Item Type: Sensor Material: PC-V0 fireproof material Model: XKC-KD200-NPN-NO Working Voltage: DC5-24V Sensing Distance: Approx. 0.3-180cm / 0.1-70.9in adjustable(There is a certain error between the sensing distance and the obstacle color, light color is far away, dark color is close) Sensing Angle: 30-40° cone angle Sink Current: Load Current: Working Temperature: -20-85℃ Storage Temperature: -20-85℃ Wire Length: Approx. 30cm / 11.8in (±10mm / 0.4in) Waterproof Rating: IP67

How to Use: Open hole on the panel where the sensor needs to be installed. The hole diameter is28mm. Install the sensor into the hole from the front of the panel, and tighten the nut behind the sensor.

Package List: 1 x Sensor
