NAS server TS-864eU-8G 8x0HDD Intel Celeron N5095 8GBNas server TS-864eU-8G 8x0HDD Intel Celeron N5095 8GBNas server TS-864eU-8G 8x0HDD Intel Celeron N5095 8GBTS-864eU is a rackmount NAS server with a shallow chassis, designed for installations where space saving and convenient cable management are important. The 1U design makes it easy to place the device in rack environments where organized access to network resources and storage is important.
This model uses a quad-core Intel Celeron N5095 processor, allowing for smooth operation in typical office and business applications.. The version with 8 GB of RAM provides comfortable handling of many tasks related to data storage, sharing, and protection.
The TS-864eU works well as a central file storage location for small and medium-sized businesses, as well as for departments that need organized access to documents, multimedia materials, and backups.. It can be used to create a local workspace and for integration with network infrastructure.
The advantage of the device is the combination of a compact design with functions typical of modern NAS servers.. The shallow housing facilitates installation in telecommunication cabinets and places where mounting space is limited.. This form of construction helps to better utilize the available installation space.
In daily use, the server can be used for storing team data, sharing files on the local network, and organizing an archive of company materials.. It also works well as an element of the environment for working with backups and resources available to multiple users.
The HDMI output increases operating convenience in selected scenarios when a local preview or configuration using a monitor is needed.. This allows the device to be more easily deployed and managed at the installation site.
The possibility of expansion via PCIe provides greater flexibility in tailoring the system to the user's needs. This allows the configuration to be developed along with changes in requirements for storage, communication, or additional functions.
The housing has been prepared for operation in continuous applications where operational stability and orderly organization of equipment in the rack cabinet are important.. This format facilitates easier maintenance of the installation and more convenient operation during expansion or servicing.
The TS-864eU is a practical solution for environments that require efficient data storage without taking up a lot of space.. The set of device features supports both current teamwork and long-term resource storage.
The combination of an Intel Celeron N5095 processor, 8 GB RAM, a 2.5GbE interface, PCIe expansion capabilities, and an HDMI output creates a cohesive base for operation in a small server room or IT cabinet. The device's design meets the needs of users looking for a compact, rack-mounted NAS for everyday use.
Specifications:
TS-864eU
1U rack enclosure
Housing plate
8 bays for HDD/SSD drives
Intel Celeron N5095 Processor
4 cores
8 GB RAM
2.5GbE Network Interface
HDMI Output
PCIeProcessor expandability: 4-core/4-thread Intel Celeron N5095 processor with a boost clock speed of up to 2.9 GHzMemory type : SODIMM DDR4Disk type: HDDDisk type : SSDForm factor (width): 2.5'' (SFF)Form factor (width) : 3,5'' (LFF)HDD interface: SATA II - 3 Gb/sHDD interface : SATA III - 6 Gb/sHot-swapping support: YesRAID: YesRAID levels: 60 (6+0)RAID levels : 0RAID levels : 1RAID levels : JBODRAID levels : 10 (1)RAID levels : 5RAID levels : 50 (5+0)RAID levels : 6Network architecture: GigabitEthernetNetwork interface: 2 x 10/100/1000/2500 Mbit/sI/O connectors: 2 x RJ-45 LANI/O connectors : 1 x HDMII/O connectors : 2 x USB 2.0 I/O connectors : 2 x USB 3.1Fan: 6 cmHousing: Rack 2UExpansion slots: 1 x PCIe 3.0 x 2Power supply: 300W Power Supply, 100-240 VDimensions: 88.6 x 482.14 x 318.13 mmEAN: 4711103082195Manufacturer: QNAP2099.68QNAP
