The MD-14B7 motion detector is designed to control lighting or other electrical devices powered by 230V AC. Detecting motion within the sensor's field of view applies power to the receiver for a period determined by the setting of the built-in delay timer.
Additionally, the device is equipped with a light intensity sensor and a maximum light intensity regulator at which the detector is activated. A built-in switch, outside of PIR mode, in which the detector controls the receiver's power supply, allows you to turn on or off the controlled device – bypassing the detector's status.
The maximum load of the detector's relay is 500W for a resistive load or 200W for an inductive load. The device is designed for installation in suspended ceilings.
• Sensor type: Passive infrared (PIR)
• Detection angle: 360 °
• Range: Ø 6 m
• Application: For indoor use
• Sensitivity adjustment: 3 ... 2000 Lux (manual adjustment)
• Recommended mounting height: 2.2 ... 4.0 m above the floor (wall mounting)
• Bracket adjustment: None
• Lighting switch-on time adjustment: 10 s ... 15 minutes
• Maximum output load: 500 W (resistive load) 200 W (resistive load) inductive)
• Pet immunity: None
• Power supply: 220 V ... 240 VAC@ 50Hz
• Protection class: IP20
• Color: White
• Weight: 0.06 kg
• Dimensions: Ø 50 x 67 mm
• Operating temperature: -20 °C ... 40 °C
• Manufacturer / Brand: EL HOME
• Warranty: 2 years
PIR SENSOR MD-14B7 AC 230V FOR EL HOME LIGHTING CONTROL
