Feature:
1. 12Gbps Video Memory Speed: Powerful image processing capabilities, 1410MHz 1590MHz (gaming, acceleration) core frequency, 12Gbps video memory speed; for gamers to bring ultra high performance, ultra high resolution and a very visually amazing gaming experience.
2. 3D Features: Excellent 3D features, support for DirectX 12.1, for Ansel, for G Sync, for Highlights, for OpenGL 4.6 4K 8K virtual reality.
3. Support OS: HD Multimedia Interface 2.0b, DP 1.4a interface only, compatible with for Windows 7 10 11 (64 bit only) operating system. Support half height chassis.
4. PCB Material: Completely cover the card s metal backplane, making the card more robust, PCB material, to ensure a long and stable high performance output.
5. Cooling System: One piece cooling module for fast cooling, increased cooling module infusion space, so that the fan brings a strong wind quickly through to take away the core heat.
Specification:
Item Type: 4G GDDR6 Graphics Card
Material: PCB, Metal Aluminum
Model: GTX1650 4G D6 LP
Core Code and Process: TU117 12nm
Unified Shader: 896
Core Frequency: 1410MHz 1590MHz
Memory Speed: 12Gbps
Memory Capacity and Specifications: 4G 128bit GDDR6
3D Features: For DirectX 12.1, for Ansel, for G Sync, for Highlights, for OpenGL 4.6 4K 8K Virtual Reality
OS Features: For Windows 7 10 11 (64 Bit Support Only)Cooler: Original (Single Fan)
Fan Features: 2Pin, Adjustable Speed, No Speed Value Displayed
Bus Interface: PCIe 3.0 x16
Output Interface: HD Multimedia Interface 2.0b, DP 1.4a
Maximum Resolution: 7680x4320 (DP Interface)
Sli Crossfire: Not Supported
Power Supply Design: 3 Phase
External Power Supply: No
Product installation
1. Turn off the power and unplug all connectors; disassemble the main box.
2. If any other graphics card is installed on the motherboard, please unplug it first, and then insert the new graphics card into the PCI Express X16 slot provided by the motherboard.
3. If the graphics card comes with an additional power supply input interface, please find the corresponding plug on the host power supply, and insert the graphics card, please use these adapter plugs and connect the graphics card to provide enough power to the graphics card.
4. Tighten the fixing screws on the bezel of the graphics card to confirm that the graphics card is properly fixed.
5. Cover the case, reconnect all peripheral device connectors, and then insert the monitor connector into the corresponding interface on the graphics card.
6. If you need to use the TV OUT, High Definition Multimedia Interface, DisplayPort and other interfaces of the TV or display device, please first confirm whether the graphics card has the corresponding interface, if so, directly use the corresponding cable to connect the display device and the graphics card. meet your needs.
Driver Installation
1. The driver installation of the graphics card is required to be performed when the graphics card hardware is installed for the first time.
2. Please check the model number of the graphics card marked on the box or the product nameplate on the back of the graphics card. your graphics card model number starts with for GTX GT; if your graphics card model number starts with RX R, please click for AMD Series .
3.According to the specific model of the graphics card, please enter the corresponding product page and click Driver Download to download the corresponding driver according to your installed OS version.
4.After the driver download is complete, double click the file to start the installation, please follow the installation wizard instructions to install. After the installation is complete, please restart your computer..
Package List:
1 x
4G GDDR6 Graphics Card1 x Half Height Baffle
Note:
Please note that the appearance and structure of the product are random.
