Generator Controller Module for Generator with Start and

20D is one module used for Engine or Generator. It is with the functions of Auto StartCelsiusStop, and Alarm indication. Power and Running situation is indicated on the front panel. The status of the engine and generator can be checked conveniently. Features: 1. 20D is one module used for Engine or Generator. 2. It is with the functions of Auto StartCelsiusStop, and Alarm indication. Power and Running situation is indicated on the front panel. 3. The status of the engine and generator can be checked conveniently. 4. Over Frequency, Low Frequency, Over Voltage, Under Voltage, Low Oil Pressure, High Temperature, Low Water , Low Oil , Failure, Over-time Stop, Emergency Stop Alarm System as well as Low Battery Voltage can be indicated in time. 5. The output contact adopts relay, which can withstand large output current, and can set system parameters according to the button, so as to meet the application of different . Main Features:

-computer Control ManualCelsiusAuto StartCelsiusStop 5 Units LED tube Display LED and Fault Alarm Indication Two Group of programmed Relay output Application for various kinds of Engine by self-setting Control Function: Automatic control of the car Start delay control Local manual startCelsiusstop Remote automatic startCelsiusstop Automatically restart the motor from, the oil pressure back to the motor Preheat control Cold machine control ParkingCelsiusidle control The parameter display: Engine speed Generator frequency Generator AC voltage Engine battery voltage Engine oil pressure Engine water temperature Cumulative running time

Function: Lubricating oil pressure Low cooling water Cooling water temperature Generator overvoltage OverclockingCelsiusoverspeed Generator set emergency stop Engine downtime failed Engine start failed Low fuel warning Low battery voltage warning Configuration : Configuration parameters via controller front panel buttons  Specification: Condition: 100% Brand New Item Type: Generator Controller

Supply: 8-36V Power Consumption: 3W Measuring Frequency: 10-70Hz Input voltage range: AC 20-276V Relay Output: Fuel Output: 3.5A Start Output: 3.5A Configurable relay output: 3.5A Excitation output: 3.5A Size: Approx. 78mm * 75mm * 76mm Celsius 3.07 * 2.95 * 2.99in Hole Size: Approx. 67mm * 67mm Celsius 2.6 * 2.6in

Temperature :-30 celsius -70 celsius Storage Condition:-40 celsius -85 celsius Panel: ChineseCelsiusEnglish Optional Package List: 1 * Controller Note: 1. Please allow slight error due to manual measurement. Thanks for your understanding. 2. Monitors are not calibrated same, item color displayed in photos may be showing slightly different from the real object. Please take the real one as standard.
