Features:
Dual Functions: combine the functions of surface temperature measurement and real-time thermal imaging.
Time Saving: no need to measure each component one by one anymore, saving your time.
Clear Images: with the 2.8" 240*320 full color display screen, this thermal camera can help you observe the full range of infrared images.
Image Overlapping: it is easier for you to understand the infrared images by using aligned visible images and infrared images. The use of image overlapping can capture the visible image of every infrared image so as to display the temperature distribution in the target region correctly and share with other people more effectively.
5 Selectable Color Palette: rainbow, iron, cold color, white hot, and black hot. The monochrome palette makes it easier to spot subtle differences, while the high contrast palette helps you quickly find obvious anomalies. Capable of choosing the suitable color palette according to your different needs.
celsius / Fahrenheit Switchable: the temperature range of this infrared camera is -25~550 degrees C (-4~1022 degrees F), and you can switch units of Fahrenheit and Centigrade in the Settings.
Image Output & Browse: the saved images through capture may be checked and output by connecting with a computer through Mirco USB. The supported operating system includes Win7, win8, win10, XP, and iOS system.
Wide Applications: perfect for car engine overhaul, transformer room line maintenance, air conditioner repair, etc. in electric power, electronic manufacturing, industrial inspection and other fields.
Specifications:
Material: PC
Infrared Detector Type: Vanadium oxide uncooled infrared focal plane
Infrared resolution: 120*90
Field Angle: 26 degrees *19 degrees
Cell Size: 12um
NETD: 550mK @25 degrees C, @F/1.1
Thermal Imaging Frame Rate: less than 25Hz
Lens Focal Length: 3.2mm
Emissivity Setting: 0.01-1.00 adjustable
Infrared Response Band: 8-14um
Focus Mode: Free focus
Temperature Measurement Range: -25~550 degrees C (-4~1022 degrees F)
Measurement accuracy: +/-2 degrees C (35.6 degrees F) or +/-2percent
Temperature Measurement Mode: Center point/hot and cold spot tracking
Color Palette: Rainbow, iron, cold color, white hot, black hot
Display size: 2.8-inch (240*320)
Image Display Mode: Infrared/visible light/dual light fusion
Lighting System: LED fill light
Device Storage: Built-in 4G eMMC (user available storage space is about 3G)
Storage Image/Video Format: JPG/MP4
Image/Video Export Method: USB connection to computer export
Menu Language: English, Chinese, Italian, German
Battery Type: Removable rechargeable li-ium battery
Battery Capacity: 2000mAh
Working Time: 2-3 hour
Power Interface: Micro USB
Power Configuration: 5 minutes / 20 minutes / no automatic shutdown
Work Temperature: -10~45 degrees C (14~122 degrees F)
Storage Temperature: -20~60 degrees C (-4~140 degrees F)
Relative Humidity: 10percent ~85percent RH (non-condensing)
Item Size: 226 * 96 * 72mm / 8.90 * 3.78 * 2.83in
Item Weight: 390g / 13.76oz
Package Weight: 711g / 25.08oz
Package Size: 25.5 * 12.8 * 8.7cm / 10.04 * 5.04 * 3.43in
Package List:
1 * Thermal Imager
1 * USB Cable
1 * Manual (English)
