Description:
- Module Properties: Non-isolated step-up module
- Input Voltage: 8~32V input(the default is 10~32V input.)
- Input Current: 5A (Max)
- Quiescent current: 15mA (12V liter 50V, the output voltage, the higher the current will increase too quiet)
- Wiring: free welding output terminals
- Size(L*W*H): Approx. 60 x 50 x 20 mm / 2.36x1.97x0.79inch
Specification:
- Output Voltage: +45~390V continuously adjustable (default output ±50V)
- Output Current: 0.2A Max(with input, output pressure related,the higher the output voltage, output current is smaller)
- Output Power: 40W (Peak 70W)
- Working Temperature: -40 ~ + 85 degrees (ambient temperature is too high, please enhance heat dissipation)
- Operating frequency: 75 KHz
- Conversion efficiency: up to 88% (efficiency and input and output voltage, current, pressure-related)
- Short circuit protection: Yes.
- Over current protection: Yes. (Input current exceeds 4.5A, reducing the output voltage)
- Over voltage protection: Yes. (Output voltage exceeds 410V, lowering the output voltage)
- Input reverse polarity protection: Yes ( reverse burning fuse, try not reversed.)
- Installation: Four 3 mm screws
- Applications:
- 1.Pressure test power.
- 2.Hunting,eradication of mice.
- 3.Capacitor charging,electromagnetic guns power supply.
- 4.The power supply for your electronic device, according to your system can set the output voltage value.
Package Includes:
1 Piece of Booster Module
