Feature:
1. Support thermocouple, thermal resistance, voltage, current and two?wire transmitter output.
2. It is suitable for the measurement and display of various physical units such as temperature, pressure, liquid level and length.
3. High?precise linear calibration can be performed on various linear models. Adopt advanced five jumper technology to freely change the index number.
4. It adopts high?brightness LED digital display and high?precise 40?line column display, which clearly and intuitively displays the measured value.
5. Support up to four alarm functions, including two upper limit and two lower limit alarms, which can be independently alarmed.
6. It has a variety of standard serial two?way communication functions (RS232C, RS?485, RS?422, etc.).
7. Equipped with an intelligent data collector and configuration software based on for WindowsXP platform, the upper computer can be networked.
Specification:
Item Type: Liquid Level Transmitter
Material: Plastic
Color: As shown in the picture
Model: OMST8030123HLP
Application: Can measure various conductive liquids
Scope of Application: Have applications in industry, petroleum, chemical, pharmaceutical, and textile industries
Measuring Range: 1999~1999 words
Power Supply Voltage: AC220V 50HZ
Measurement Accuracy: 0.5percent FS
Power Consumption: less than 5W
Output Specifications:
1. Thermocouple: B, S, K, E, T, WRE, etc.
2. Thermal resistance: Pt100, Cu50 and other remote pressure resistance
3. Linear voltage: 0~5V, 1~5V, 0~10V, 1~10V, etc.input impedance more than 250 Ohm
4. Linear current: 0~10mA, 0~20mA, 4~20mA, etc.input impedance less than 250 Ohm
5. Linear resistance: 0400 Ohm (can be used to measure remote resistance pressure gauge)
Use Environment:
1. Ambient temperature 0~50 celsius
2. Relative humidity less than 85RH
3. Avoid strong corrosive gas.
Package List:
1 x Liquid Level TransmitterSupport thermocouple, thermal resistance, voltage, current and two?wire transmitter output.
It is suitable for the measurement and display of various physical units such as temperature, pressure, liquid level and length.
High?precise linear calibration can be performed on various linear models. Adopt advanced five jumper technology to freely change the index number.
It adopts high?brightness LED digital display and high?precise 40?line column display, which clearly and intuitively displays the measured value.
Support up to four alarm functions, including two upper limit and two lower limit alarms, which can be independently alarmed.
