Size:40 cm
Origin : Mainland China
Hign-concerned Chemical : None
Model Number : 5425-400
Certification : CE,RoHS
Material : Aluminum Alloy
Battery : 2pcs AAA battery (not included)
Length : 400mm
Measuring range : 0-225 degree
Resolution : 0.05 degree
accuracy : ±0.5 degree
Note: The parcel will be sent without battery ,The battery type is 2 pieces AAA battery
Characteristic & Function
1. This product adoptshigh-strength aluminum alloyto the ruler body, which is durable.
2. This product uses a high-definition LCD screenwith backlightfunction, so the backlight will automatically turn on during use. The backlight will automatically turn off after 30 seconds of nonuse, so this product can also be used normally in low-light and dark environments.
3. This product has the automatic shutdown function after three minutes of no response.
4. This product is mainly used in construction, woodworking, machine work, home DIY, etc.
Technical Data
Button Function
ON/OFF/ZERO button: In the power-on state, short press has the function of reseting. Long press has the function of shutting down. In the shut-down state, short press has the function of turning on.
HOLD button: press shortly so as to lock and unlock.
MODE button: press shortly so as to switch between ° and ′.
Measurement method
Angle measurement:
1. Adjust the position of the main ruler and the auxiliary ruler to a measurement angle (any angle within the range of 0°~225°), press the "ON/OFF/ZERO" button short so as to reset the ruler.
2. Use the top surface of the main ruler and the bottom edge of the auxiliary ruler to measure another angle (0°-225°)
Horizontal and vertical measurement:
1. The measurement method of horizontal bubbles:
A. Place the bottom surface of the ruler tightly on the surface of the measured object. If the bubble in the horizontal bubble in the corresponding direction stays between the marks on the surface of the horizontal bubble, then the surface will be horizontal or vertical.
Features:
As a common measuring tool, the horizontal scale plays an important role in construction, decoration and mechanical manufacturing.
It is widely praised for its simple design and precise measurement functions.
The body of the level ruler is made of a durable material to ensure the stability of the measurement.
Whether it is installing doors and windows, laying floors, or debugging mechanical equipment, it is an indispensable right-hand assistant.
Help staff to quickly and accurately complete level measurements to ensure the accuracy and quality of the project.
