【Voltage Compatibility】
When using electrical appliances, please note that they are designed for Japanese voltage specifications (90-110V), so if you use them with a different voltage, it may cause a malfunction.
【Plug Type】
Our products use Japanese plug types (A or B type).
Please use a conversion adapter if necessary.
【Important Note on Transformers and Adapters】
A transformer adjusts voltage to match your device’s requirements.
A conversion adapter only changes the plug shape and does not adjust voltage.
Using only a conversion adapter without a transformer may result in damage to the product.
【Liability】
We are not responsible for malfunctions or damages caused by improper use, such as operating the product without a transformer.
----------------------------------------------------------------------
[Open-jaw design]: This smart digital multimeter features an open-jaw design that allows for easy measurement in tight spaces such as inverters, hubs, and concentrated lines.
[Smart Mode]: The true RMS multimeter can automatically measure AC and DC voltage, resistance and continuity with the highest resolution, all of which can also be measured manually.
[Triple Design]: The pocket multimeter can be used not only as a DC/AC amp clamp meter, but also as a professional voltage tester.
[Automatic Amplifier Identification]: The digital clamp multimeter can automatically measure DC and AC current with its jaws, and the measurement can also be done manually.
[Rechargeable]: The digital voltmeter is rechargeable and comes with a charging cable, ensuring you don't have to worry about running out of power during your measurements.
Features: Color display clamp meter True RMS digital smart multimeter Open jaw design with rechargeable battery Professional DC AC current clamp ammeter Also can be used as a professional voltage tester Measures capacitance, diode, duty cycle, environmental temperature Measures voltage, resistance, frequency, continuity, V Alarm and live wire inspection Auto range, auto power off, low display with flashlight
Specifications: Display 6000 counts DC Current: 1-100A 0.1A ±(2.5%+5) AC Current: 1-100A (40-100Hz) 0.1A ±(2.5%+5) DC Voltage: 0.001-5.999V 0.001 V ±(0.8%+3); 6-59.99V 0.01 V ±(0.8%+3); 60-599.9V 0.1 V ±(1%+5); 600-610V 1 V ±(1%+5) AC Voltage: 0.05-5.999V 0.001 V ±(1%+3); 6-59.99V 0.01 V ±(1%+3); 60-599.9V 0.1 V ±(1.2%+5) 600-610V 1 V ±(1%+5) Resistance: 0.1-599.9ω 0.1ω ±(1.2%+3); 0.6k-5.999kω 0.001kω ±(1.2%+3); 6k-59.99kω 0.01kω ±(1.2%+3); 60k-599.9kω 0.1kω ±(1.2%+3); 0.6m-5.999mω 0.001mω ±(2%+10); 6m-60mω 0.01mω ±(2%+10); Capacitance 0.01µF-5.999µF 0.001µF
±(3.5%+8); 6µF-59.99µF 0.01µF ±(3.5%+8); 60µF-599.9µF 0.1µF ±(3.5%+8); 0.6mF-5.999µF 0.001mF ±(4.5%+10); 6mF-60mF 0.01mF ±(4.5%+10) Frequency 1-9.999Hz 0.001Hz ±(2.0%+10); 10-99.99Hz 0.01Hz ±(2.0%+10); 100-999.9Hz 0.1Hz ±(2.0%+10); 1K-9.9KHz 0.001KHz ±(2.5%+12); 10K-99.9KHz Frequency: 0.01KHz ±(2.5%+12); 100K-999.9KHz 0.1KHz ±(2.5%+12); 1M-9.999MHz 0.001MHz ±(3%+15); Duty Cycle: 10%-95% 0.1±3 Diode Measures diodes within 3.0V Continuity: Beeps when resistance is less than 50Ω Temperature 0-50℃ ±2℃ V Alert: Yes Live Wire Check: Yes Power Supply: Rechargeable 3.7V (Built-in) Size: 192 x 36 x 30mm
Tor Weight: 102 g
Package Included: 1 x Digital Clamp Meter 1 x Test Leads 1 x Charging Cable 1 x Carrying Case 1 x Battery 1 x User Manual
